Embossing MS IC RFID Card Personalization Machine 300DPI Automatic Card Dispenser

Detailed Product Description
Print Type:: 300DPI Direct Print Or Customization Encoding:: MS/IC/RFID Read &write
Power Supply: 24V +/-10% 20A Communication: USB Interface
Application: Gaming,vending Type: Card Personalization Machine
High Light:

Embossing MS Card Personalization Machine

,

IC RFID Card Personalization Machine

,

300DPI Automatic Card Dispenser

Full Function Card Personalization Machine



• Embossing/Indenting(name+date)+ Tipping gold/silver
• Print type: 300DPI direct print or customization
• Card storage capacity: 500pcs or more
• Input card capacity: 200pcs * 6 hoppers
• Reject card capacity: 50pcs or customization
• Encoding: MS/IC/RFID read &write



Specification:

Support card type

Support to operate contact & contactless IC card in banking field,

magnetic card read only

Length:85.47-85.90mm

Width:53.92-54.18mm

Thickness:0.76 mm~1.0mm

Power supply

24V +/-10% 20A

Idle current: ﹤3A

Card storage module

Capacity:500 pcs

Support to manually check card slot, holder, ensure the cards have

been cleared

Support the card slot for the card in or out at the specified position

Support the card feeding cassette status checking

Cassette

6*100PCS flat cards

with the function of card empty, card less and normal detection

Retrieve the cards

Cassette for clearing the cards capacity﹥150 flat card,with lock

Error card bin capacity﹥150 flat card,with lock

With the function of card empty-normal-full detection

Printer

Support direct printing function of thermal sublimation

technology, resolution: 300 dpi supports single / double sided

printing

Embossing and

tipping module



Support embossed surface gold or silver tipping,Hot ribbon

support 1000 pieces

Support back indenting carbon tipping, with a capacity of 1000

carbon tipping ribbons

OCR scanning Resolution: 300 dpi supports single-sided / double-sided scanning
Communication USB interface
Error rate

The error rate of the whole machine is less than 3/1000

The whole process card printing success rate is not less than 99.7%



Environment

Operation temperature and humidity :5~50 ℃, 20% ~ 80%RH(non condensing)

Storage temperature and humidity:-20~70 ℃, 20% ~ 80%RH(non

condensing)

Weight



About :150kg (without accessories and packages)


Applications:

Self-service national ID card dispenser, BANK card issuing, Driver license issuing.....
